LM Drum

Hybrid Sampling Drum Machine

• 16 instruments – drums and percussion
• Trigger pads for each instrument plus mixer with volume and panorama controls
• 109 sounds
• Sampling engine with 8-bit/12-bit and 16 DA converters with variable sampling rate
• Tuning controls for snare, toms, and congas, and control for hi-hat decay
• Wave designer with adjustment options for attack and sustain
• Assignable analogue filter (low-pass/high-pass) with controls for cut-off and resonance
• 64-step sequencer with poly meter, step repeat, note repeat, real-time triggering, track mute, and track solo
• Up to 8 songs and 128 patterns can be stored
• Auto-scroll function
• LC display
• Dimensions (W x D x H): 479 x 264 x 73 mm
• Weight: 3.12 kg
• Including external power supply unit (12 V DC)

Connections.

• Line input for recording the user’s own samples: 6.3 mm jack
• Stereo line output: 2 x 6.3 mm jack
• Stereo headphone output: 6.3 mm jack
• 16 individual outputs for instruments: 3.5 mm jack
• 3 assignable trigger outputs: 3.5 mm jack
• Sync input/output: 3.5 mm jack
• MIDI In/Out: 5-pin DIN
• USB-B port
